Range Rover Classic Buying Guide
Price are going wild! But are there any bargains left? And if there are, how do you find one? Here are the answers...
How much to pay
• Project £800-8500 • Good £5800-30,000 • Concours £20,000+ •
Running costs ★★
DIY Friendly ★★★★
The Range Rover is generally regarded as the world’s first truly luxurious SUV. Jeep Cherokee and Wagoneer fans might beg to differ, while the earliest Range Rovers were far more utilitarian than plush, but there’s no denying that this timeless Land Rover created a template for all to follow.
When it arrived in 1970, the Range Rover was aimed at gentleman farmers who wanted something as capable on the road as off it, with which they could tow, transport the family or travel long distances. The Range Rover provided a perfect solution with its generous ground clearance, permanent four-wheel drive and torquey 3.5-litre V8.
Now that the original Range Rover is firmly established as a very desirable classic, these cars rarely venture off road. The earliest cars (with two doors) are the most collectible and these rarely get used at all. Their loss, as when it comes to stylish transport, few cars can beat the Range Rover Classic.
Your AutoClassics Range Rover Classic inspection checklist
With the V8 engine fitted exclusively until 1986, oil changes at least every 6000 miles are the key to a long life. Without these the camshaft wears rapidly, so if things sound very tappety, especially when the engine is cold, expect a big bill soon. Don’t worry too much about low oil pressure as the gauge fitted to pre-1984 cars is notoriously inaccurate; the engine will work quite happily with low oil pressure anyway. The V8’s alloy cylinder heads corrode internally if anti-freeze levels aren’t maintained while 3.9-litre engines can suffer from premature rocker wear and porous blocks.
Fuel-injected Range Rovers often suffer from starting problems, erratic running and misfiring because of ECU or airflow meter glitches. The fuel filter (on the nearside inner wing) is sometimes removed, which leads to the fuel system getting clogged up.
The VM turbodiesel engine is torquey but unrefined. The most common problem is blown head gaskets and there are four of them thanks to the engine’s modular construction. All four must be replaced for a long-lasting repair – or fitting a 200 TDi engine is a better option. That’s what Land Rover eventually resorted to.
The 200 TDi and 300 TDi engines are much better in every way than the VM units, but they must have a fresh timing belt every 60,000 miles. If this fails the engine will be wrecked. The oil must also be replaced every 6000 miles or the turbocharger’s bearings will be ruined.
Land Rover Range Rover 2017
Virtually cannot be told from new Only one executive owner 510 hp supercharged V8 engine Stored in a heated garage Only 10,500 miles! Full annual service just performed by Land Rover in March 2018! Well under factory warranty The most desirable color combination Incredibly well optioned with: Front & rear comfort A/C Heated & air conditioned seats Meridian sound systFor Sale | 01 May 2018 | St. Louis, MO, USA$ 96,900
1986 Land Rover Defender 110
This 1986 Defender 110 is in excellent shape with a nice satin grey paint job and a new black mohair soft top. The 200TDI engine runs strong. The 5 speed transmission is smooth and the gear changes are without grinding or noise. The interior has been completely redone with new original half leather Land Rover XS front seats and 8 new black flip up seats in the rear. The interior floors have beenFor Sale | 28 Apr 2018 | Aventura Motors 625 County Rd 39A, Southampton, NY 11968$ 79,000
Land Rover Discovery 2.5 TDI XE Automaat
Robuuste Land Rover Discovery uitgevoerd met de degelijke en krachtige 2.5 TDI techniek en automatische transmissie. Betreft een grijskenteken uitvoering, de wegenbelasting voor de zakelijke rijder komt op ongeveer �?�40,- per maand. Prijswijzigingen, druk- en zetfouten voorbehouden. Altijd ruim 500 auto`s op voorraad, check de actuele voorraad via www.hofman.nl. Volg ons ook op facebook.com/HFor Sale | 20 Apr 2018 | Rodenburg 1, 9351 PV Leek€ 2,990
1984 LAND ROVER DEFENDER 90
RIGHT HAND DRIVE, FRESHLY REBUILT 2.5L DIESEL, 5 SPD MANUAL, STRAIGHT & CLEAN!!! If you have someplace remote to get to, this 1984 Land Rover Defender 90 is the right tool for the job. Freshly refinished with beautiful green paint and a rebuilt diesel powerplant, it`s ready to enjoy regardless of whether you take it to shows or get it dirty in the mud. Looking at the lines of the Defender 90, youFor Sale | 19 Apr 2018 | 5400 Sandshell Dr, Suite 100, Fort Worth, TX 76137$ 31,995
1986 Land Rover Defender 110
Gateway Classic Cars of Scottsdale is proud to offer this hard-to-find 1986 Land Rover Defender 110 (which is the truck`s wheelbase) in white with a very roomy and stylish black leather interior. This one`s equipped for serious duty with a 4.0L V8 with a five speed manual transmission, four wheel drive, no creature comforts like AC or a radio, and plenty of ground clearance to make sure you can goFor Sale | 16 Apr 2018 | 22275 North 23rd Ave, Deer Valley, AZ 85027$ 49,995
Land Rover Defender 90 2.5 TDI
goed rijdende landrover defender, weinig miles, rhd. voorzien van niewe schokbrekers, veren en speciale rubbers in de wielophanging. Prijswijzigingen, druk- en zetfouten voorbehouden. Altijd ruim 500 auto`s op voorraad, check de actuele voorraad via www.hofman.nl. Volg ons ook op facebook.com/HofmanLeek. Prijswijzigingen, zet en drukfouten voorbehouden.For Sale | 16 Apr 2018 | Rodenburg 1, 9351 PV Leek€ 6,990
1973 Range Rover Safari
Mayfair 020 7125 1400 | Maldon 01621 879579 1973 Range Rover This Suffix B Range Rover was constructed in October 1973 in Lincoln Green with a Palomino interior and has a fascinating history having been first owned by Jaguar racing driver Duncan Hamilton, and then used by the ITN journalist Michael Nicholson in his epic 14,000 mile journey home from South Africa to England, which was immortalisedFor Sale | 27 Jan 2018 | JD Classics Mayfair 26-28 Mount Row Mayfair London, W1K 3SQ£ POA
The four-speed gearbox tends to whine, so don't expect silence. However, if one gear is even noisier than the rest it’s likely that there’s a rebuild on the horizon.
Off-roading can damage any of the three differentials, so look for cracks and oil leaks from the casings. Even when in good condition there tends to be slack in the transmission.
Try the car in both high and low ratio. Switching between the two uses a vacuum-operated system that can be slow to engage – especially if the car hasn’t been switched between the two for a while (if ever).
Suspension and brakes
Steering box oil leaks are par for the course, which means an MoT failure; replacement seals will fix things for a while. Any stiffness will be down to seized universal joints in the column (easily fixed) and if the steering feels particularly vague it should just need adjusting – as long as there’s some adjustment left. Cars used sparingly can suffer from the swivel balls corroding and leaking, and fitting new ones is the only fix, but it’s not an expensive one.
Right from the beginning the Range Rover got self-levelling suspension and it’s very effective – as long as it’s working. Between the chassis and axle is a Boge Nivomat strut, which can fail and it’s not cheap to replace – although it’s not outrageously expensive either. Some owners opt for stiffer springs instead, spoiling the ride quality, which is one of the many brilliant things about the Classic.
Check for rust around the front damper mounting flanges and see if the suspension bushes are on their last legs – they’re easy enough to replace though. More tricky is corroded mountings for the rear shock absorbers, which are retained by a split pin that allows movement, leading to wear.
The handbrake works on the rear output shaft of the transfer gearbox, and if it’s used to slow the car it can damage a halfshaft, propshaft or the brake shoes.
Corrosion in the tough ladder frame chassis is unusual, but if there is any it will be over the rear crossmember. If there’s significant rust over the rear wheels the bodyshell will have to be removed to effect proper repairs. There’s also a bracket just above the rear springs, which holds the bodyshell in place. This rusts away leaving the body resting on the chassis, which damages the car's structural integrity.
The aluminium outer panels get damaged easily and they corrode, especially where the alloy meets the steel structural panels. Focus on the area where the front wings meet the inner panels, the bottom of each door and wing. Post-1985 cars have aluminium panels bolted to a steel frame, so check for corrosion in the front footwells, sills and the rear floor around the wheelarches. Pre-85 examples were crafted from lesser steel, rusting far quicker and far more aggressively. Exposed hinges and panel gaps must be investigated, as these can indicate the health of the concealed metal areas.
Next home in on the door hinge mounts on the A-pillars. Rot here is common, while the heavy doors of two-door cars tend to strain the hinges and A-posts. Once the doors start to sag you're looking at repairs to the sills and A-post, which is not going to be cheap. Also expect rust in the steel bonnet; glassfibre replacements are available.
Rust in the upper half of the tailgate is common; check the seams and bottom corners. Post-1984 lower tailgates last well but those on earlier cars are water soluble and as with the top section, replacement rather than repair is the only option. Make sure the locks on the top-half of the tail gate are not seized open, as this can result in the rear window becoming a large spoiler.
The sills are structural so must be in good condition, but they’re often not. Fuel tanks rot too, and if you find a Monteverdi four-door Range Rover just bear in mind that the converted bodywork was all bespoke, so repairs have to be fabricated from scratch.
The seats were trimmed in PVC until 1974 when cloth trim generally took over; leather arrived in 1988, as an option. The PVC splits and repairs are tricky if not impossible, which is why most cars are now trimmed in leather or cloth. Headlinings separate from the retaining panel, with replacement the only solution.
Early Range Rovers have very simple electrics, with just three fuses in the fusebox plus another in the wiring loom. However, any Range Rover can suffer from the wiring loom going brittle in the engine bay because of the heat. If the car has a tow bar fitted, see how well the electrics have been spliced into.
- 1970: The Range Rover debuts in three-door form only, with a 3.5-litre V8 and four-speed manual gearbox.
- 1978: Overdrive becomes available.
- 1979: There are now silver bumpers instead of black and the rear lights are redesigned. Power steering becomes standard and tinted glass is now fitted.
- 1980: Monteverdi introduces a four-door conversion.
- 1981: Land Rover announces its own four-door car.
- 1982: A three-speed automatic transmission becomes optional.
- 1983: A five-speed manual gearbox becomes standard.
- 1985: Fuel injection is now fitted, but only on Vogue models. The automatic gearbox becomes a four-speed unit.
- 1986: A turbodiesel engine is now offered. It’s a 2.4-litre VM-sourced unit. At the end of the year, carburettors are ditched altogether as is the two-door bodyshell – except for exports and special orders.
- 1989: The diesel engine is now a 2.5-litre unit and the 3.5-litre engine gives way to a 3.9-litre unit.
- 1992: The long wheelbase (108 inches) Vogue SE arrives with a 4278cc powerplant. The unrefined VM diesel gives way to a Land Rover 200 TDi unit
- 1994: The two-door cars go out of production altogether. A new dash is fitted, the 300TDi supersedes the 200TDi and the second generation Range Rover arrives.
- 1996: The final Range Rover classic is made.
How a Range Rover is used will have a big effect on its condition and durability. Most of these cars are now used sparingly and even then, only on-road. But if you find a car that’s been used in an off-road environment, the suspension, steering and brakes are much more likely to be worn out.
All Range Rover Classics have a big following, with the first year of production especially sought after. However, all two-door cars are desirable, while later four-door cars loaded with kit, in very good condition and with a low mileage will also fetch big money.
Of the later Range Rovers, those with the 3.9-litre engine are seen as the sweet spot as the engine is reliable, smooth and torquey – the 4.2 and 4.6-litre V8s aren’t as long-lived. The Chrysler-supplied three-speed auto is also a very good transmission, but the four-speed ZF unit that came later is even better. The manual gearbox is nice enough to use but most buyers want an auto as it suits the Range Rover’s relaxed nature. And when it comes to cars that are relaxing to drive, few are more so than the Range Rover.
|Range Rover 1970-1979|
|Range Rover 1979-1984|
|Range Rover VM turbodiesel|
|Range Rover 300TDi Turbodiesel|
|Range Rover 1989-1992|
Picture courtesy of Land Rover
