Porsche Cayman 987 Buying Guide
The 2005-2013 Cayman 987 is the hidden gem of modern classic Porsches, lower profile than the Boxster or 911, but no less rewarding
How much to pay
• Project n/a • Good £12,500-25,000 • Concours £25,000-45,000 •
• Most expensive at auction: £38,401
Running costs ★★
DIY friendly ★★
Heavily based upon the Type 987 Boxster – they’re the same from the waist down – the Cayman is a sweet-driving coupé that occupies a slightly awkward spot in the Porsche hierarchy. In 3.4-litre S form, it comes very close to 911 levels of performance, but it cost more than the Boxster when new and so needed to offer something over and above its open sibling.
Even if road tests tended to describe the Cayman as ‘brisk’ rather than fast, you’re unlikely to feel regularly short changed in normal conditions. Even the basic model will get to 60mph in about six seconds, and the quality of the chassis makes up for any perceived limitations in straight-line speed. The steering, accessible nature of the performance, overall agility, roadholding – it all adds up to a fabulously rewarding little package.
There are two generations of 987 to consider. The standard Generation 1 car had a 2.7-litre flat-six, with the S model boasting a 3.4 unit. For the Generation 2 model, the ‘entry-level’ Cayman was uprated to 2.9 litres.
Your AutoClassics 2005-2013 Porsche Cayman 987 inspection checklist
There were three engine variants across the 987’s production run: the M97.21 in 2.7 and 2.9-litre form, plus the M97.20 3.4-litre unit in the S. The biggest scare stories concerning the Generation 1 Cayman are to do with the intermediate shaft (IMS) bearing and scoring of the cylinder bores. The problem with cylinder scoring concerns only a small percentage of cars, with the 3.4 seeming to be worse affected. Look for excessive smoke when starting from cold, and evidence of increased oil consumption.
For the 2007 model year, Porsche fitted a stronger IMS bearing that greatly reduced the problems suffered by earlier engines. One that’s failing, however, will emit a rattle while the engine’s idling. There can also be an issue with a leaking rear main oil seal, but new replacement seals can solve that.
The Generation 2 987 – introduced for the 2009 model year – featured an all-new engine that eliminated each of the above problems, so it’s worth stretching to that if you can. With all variants, evidence of regular servicing is essential, in particular an annual oil change.
Porsche 911 (997) 3.6 C2 Gen II PDK Coupe
PDK Doppelpunkt Semi Automatic Gearbox Meteor Grey Metallic Full Black Leather Porsche PCM 3 Touchscreen DVD Satnav & Bluetooth Phone Connectivity Universal Audio Interface 19 Inch Carrera S II Alloys Heated Seats Extended Leather To Lower Rear Centre Console Park Assist Rear Parking Sensors 3 Spoke Multifunction Steering Wheel In Smooth Leather Automatic Climate Control Airconditioning PSM PorschFor Sale | 17 May 2018 | Chappell Sports Cars A27 Westbound Chichester PO19 8FH£ 43,995
Porsche 911 (997) 3.8 C2S Gen II PDK Cabriolet
PDK Doppelpunkt Semi Automatic Gearbox Basalt Black Metallic Full Black Leather Sport Chrono Package Plus Porsche PCM 3 Touchscreen DVD Satnav & Bluetooth Phone Connectivity Universal Audio Interface Bose Sound 19 Inch Carrera S II Alloys With Colour Crested Centres Heated Seats Park Assist Rear Parking Sensors Sports Seats With Crest Embossed Headrests Guards Red Seatbelts 3 Spoke Spoke Design StFor Sale | 17 May 2018 | Chappell Sports Cars A27 Westbound Chichester PO19 8FH£ 51,995
PORSCHE 911 (997) GT3 RS 4.0 GEN II, 2012, LHD
CARRARA WHITE PAINTWORK WITH BLACK ALCANTARA. FACTORY SPECIFICATION INCLUDES:- FRONT AXLE LIFT, CLIMATE CONTROL, FOLDABLE BUCKET SEATS, BLACK FACED SPORTS CHRONO PACKAGE PLUS, 90 LITRE FUEL TANK, CARBON BELT OUTLETS B-PILLAR, CARBON SIDE AIR VENTS, CARBON CENTRE CONSOLE, CARBON CENTRE AIR VENT, AUTO DIM MIRRORS AND RAIN SENSOR, CRUISE CONTROL, SOUND SYSTEM A.S.K. An opportunity to own one of the lFor Sale | 17 May 2018 | 82-92 Great North Road, London, N2 0NL£ 330,000
PORSCHE 911 (997.2) CARRERA 2 GTS, 2011
BASALT BLACK WITH BLACK HALF ALCANTARA INTERIOR. SPECIFICATION INCLUDES:- MANUAL GEARBOX, SPORTS CHRONO PLUS PACKAGE, SPORT EXHAUST SYSTEM, PORSCHE PCM WITH TELEPHONE MODULE AND BLUETOOTH, SPORTS SEATS WITH HEATING, INSTRUMENT DIALS IN BLACK. The 997 GTS is fast becoming a popular and much sought after modern classic. This example comes in the much-desired spec of being painted in black and havingFor Sale | 17 May 2018 | 82-92 Great North Road, London, N2 0NL£ 79,995
1974 PORSCHE 911 SLANTNOSE RINSPEED
RARE RINSPEED SLANTNOSE 911, 2.7L H6, 5-SPEED, TURBO BODY KIT, WHALE TAIL, SLICK. The Porsche 911 has always been iconic, but this 1974 911 slantnose by Rinspeed takes an icon and elevates it to legend. If you were a car guy back in the late `70s and early `80s, this was the car that filled your dreams and dominated pop culture. Today, it remains a heck of a lot of fun and probably not a bad invesFor Sale | 17 May 2018 | 213 Thornton Rd, Suite 400, Lithia Springs, GA, 30122$ 35,995
1974 PORSCHE 914 TARGA
WELL MAINTAINED & FUN TO DRIVE! 89K ORIG MILES, VERY STRAIGHT, CLEAN INTERIOR! Low slung, agile, and blessed with a timeless look, this 1974 Porsche 914 Targa is all about open air motoring fun. It comes with an extensive array of maintenance receipts to prove the great care it`s received over the decades, as well as build receipts and a Certificate of Authenticity to document its genuine PorscheFor Sale | 17 May 2018 | 5400 Sandshell Dr, Suite 100, Fort Worth, TX 76137$ 19,995
2000 V Porsche Carrera Tiptronic S Auto in Silver...
Finished in Silver with electric sunroof, 5-spoke alloy wheels and Black interior. Fitted with Porsche PCM sound system, sat nav, 6 CD changer, heated front seats, multi-function steering wheel, air conditioning, cruise control and rear parking sensors. 109,000 miles with good history including service book and invoices. Excellent condition inside and outFor Sale | 16 May 2018 | The Broadway, 86-91 Uxbridge Road, London W7 3ST, United Kingdom£ 13,950
PORSCHE 911 COUPE 3.8 GT3 PDK 2DR SEMI AUTOMATIC 2014
DESCRIPTION. Amari is overwhelmed to be able to offer you the outstanding Porsche 911 GT3 which is a 2014 / 64 Registered Example in White, Black Interior, having covered only 4,265 Miles only by 2 Owners from New. EXTERIOR. The gleaming exterior is presented in White, which is the true colour for the GT3 with contrasting Black Alloy Wheels, which is in an immaculate and unblemished condition as yFor Sale | 16 May 2018 | AMARI™, Wyder Court, Millennium City Park, Preston, PR2 5BW£ 129,895
2005/05 Porsche 911 (997) 3.6 Carrera 2 Cabriolet...
Presented in Arctic silver, trimmed with full black leather to the doors and dash. Options include PCM satellite navigation, 19 Carrera Classic alloys, Xenon lights, rain sensitive wipers, self dimming rear view mirror, fully electric memory seats, BOSE sound system, multi function steering wheel trimmed with smooth leather, cruise control, heated seats, rear park assist, wind deflector, automaticFor Sale | 16 May 2018 | Cridfords, The Street, Ewhurst, Cranleigh, Surrey GU6 7QY£ 29,995
Generation 1 Caymans had the choice of a manual gearbox or Tiptronic auto. The latter wasn’t ideally suited to the little coupé and for the Generation 2 it was replaced by the PDK unit, which is a completely different kettle of fish. Early PDK cars had a button system that was widely described in contemporary road tests as being counter-intuitive, but which nonetheless has its supporters among owners. Porsche later fitted paddle-shifters.
Each variant of transmission has proven to be reliable, but listen for untoward noises during the test drive, and make sure that each gear can be selected cleanly, warm or cold.
Suspension and brakes
The basic 987 came with 17in alloys as standard, but most now ride on the optional 18s. The S had those as standard, with the option of specifying 19s. Bear in mind that a car on 19s will be fine with the PASM in Normal mode, but for road use it’ll be pretty harsh in Sport. Tyres should be to Porsche’s N-rated specification. They can be identified by N1, N2, N3, etc embossed on the sidewall and should match all round.
Hard track driving in Generation 1 cars can make the hydraulic power steering pump overheat (specialists can supply modified ones) and wear out track-rod ends (Generation 2 cars had larger ones that are more durable). On the subject of circuit driving, firmer springs and dampers can help a little, but for general road use the factory set-up is already close to ideal.
The Generation 1 S Sport Edition and Porsche Design Edition 1 are lowered by 10mm, while the hardcore R drops that by another 20mm and comes with a limited-slip diff as standard.
Brakes should be strong across the range: standard models have 298mm vented discs up front, while the S boosted that to 318mm. There was the option of carbon-ceramic discs, but that’s very rare.
With even the earliest Caymans being little over a decade old, there shouldn’t be any problems with corrosion. If you do find areas of rust, they’re likely to be where accident damage has been poorly repaired – not a good sign.
The radiators are positioned in a vulnerable area at the front. They can pick up damage from stones and become clogged with debris, so have a look to see what sort of condition they’re in. Many conscientious owners have fitted grilles to the air intakes to protect them. Replacement radiators are very expensive via Porsche, but can be sourced more affordably via independent specialists.
On the subject of front-end damage, the headlamp lenses can pick up stone chips and cracks, and they’re also costly to replace.
Early Caymans can suffer from a rear-hatch rattle that might be due to it not sealing properly. The bump-stops can be adjusted in an effort to improve it, but others have pointed the finger at a small counter-weight that’s positioned in the panel to eliminate resonance. The noise comes from the suspended weight moving when the car goes over bumps. Porsche issued a Technical Service Bulletin in an attempt to fix it, but owners report varying degrees of success.
The Cayman’s impressive build quality means that interiors are holding up well, even on high-mileage cars. Inspect the seat bolsters for excessive wear, though. If the optional electric adjustment is fitted, make sure it operates correctly.
Ditto for the rest of the electrical equipment – there’s far less of that to check on the lightweight Cayman R, which ditched the stereo and air-con, and also featured bespoke seats. The Generation 1 S Sport, meanwhile, came with Alcantara trim on the seats, steering wheel, handbrake and gearlever, plus stainless-steel sill protectors.
The Porsche luggage set makes the most of the space available, and turns the Cayman into a sensible proposition for touring. Finally, make sure that the front and rear hatch releases are working properly.
- 2005: 987 Cayman S launched
- 2006: Standard Cayman joins the range
- 2008: S Design Edition 1 and S Sport Edition introduced
- 2009: Generation 2 deliveries start
- 2011: Cayman R becomes available
- 2012: New 981 Cayman replaces 987
Good looking, brilliantly entertaining and eminently usable, the Cayman marked one of Porsche's regular sweet spots. As ever, though, it would be wise to get any potential purchase inspected by a specialist. Although the headline-grabbing engine gremlins are exceedingly rare on early 987s, the Generation 2 cars did away with them altogether. Add the fact that PDK replaced Tiptronic, and you have a compelling case for the later model.
Make sure you drive the car on a road that will enable you to check whether or not the rear hatch rattles. If you ever need to occupy an hour or two, search for ‘Cayman trunk clunk’ – the forums are full of it. Hopefully, it should have been lessened if not eliminated by now, thanks to the fixes that circulated when the car was new.
A regularly used and fastidiously maintained Cayman with more miles can be preferable to a rarely driven car. Certainly, a high-mileage example is nothing to shy away from as long as it comes with a bulletproof service record.
|Cayman Gen 2|
|Cayman S Gen 2|
Picture courtesy of Porsche
