Alfa Romeo Giulia GTA Buying Guide
Lightweight GTA was developed to be the ultimate version of the already capable 105 series Giulia coupe – but you must choose carefully
What to pay
• Project £30,000-40,000 • Good £60,000-95,000 • Concours £120,000-300,000 •
• Most expensive at auction: £400,000 (Giulia GTA-SA and GTAm variants)
Running costs ★★★★
DIY friendly ★★★
Alfa Romeo built an enviable post-war reputation with a range of superb driver-focused coupes and saloons, but it achieved legendary status with the introduction of the lightweight 105 series-based GTA models.
The A stood for Alleggerita – lightweight in Italian – and the very first Giulia Sprint GTA arrived in 1965, two years after the 105 series Giulia models had been launched.
Both road Stradale and track Corsa variants were produced, most featuring aluminium panelling among numerous other weight-saving measures. The 1.6-litre engine was massaged for extra power, and the gearbox received a set of shorter ratios.
All this meant that power was up, weight was down and performance was class leading. Road-going GTA 1600s provided 113bhp, while the track variants produced up to 163bhp.
A GTA 1300 Junior followed in 1967, with slightly less power and only some of the earlier weight-saving measures. The ultra-rare GTA-SA, featuring a twin-supercharged 250bhp 1.6-litre motor, also arrived the same year.
Production numbers were low overall for all GTA variants, and many modified Giulia GTs are out there masquerading as the real thing. Specialists also offer modern-day GTA clones with a range of bespoke parts. Then there are the Evocazione recreations, which are GTA builds based on the original specifications.
Even original cars will have been subject to modifications and upgrades. The racing versions in particular tended to have led a hard life, and finding a genuine GTA requires knowledge, patience and a fair dose of good luck, too. This guide should help with the first of those points.
Your AutoClassics Alfa Romeo Giulia GTA inspection checklist
All GTA blocks were based on the Giulia alloy twin-cam four-cylinder engine. The 1.3 and 1.6-litre models used modified twin-carburettors, with the 1.6 versions also receiving a magnesium timing cover, sump and camshaft cover.
The GTA-SA was based on the 1.6-litre motor, although with slightly different bore/stroke dimensions, and it featured two superchargers.
GTAm models boasted the Spica fuel-injection system. They were based on the GTV 1750 and, later, the GTV 2000 engines. These models did not have the weight-saving magnesium components fitted to the 1.6-litre versions.
All have proven to be strong units. The few issues to look out for mirror those of the standard Giulia GT and GTV models. Timing chains and tappets can get loud over time, but they should settle down once the oil pressure is up. Have a closer look if the noise persists.
While radiators were upgraded over the standard GTV's, head gaskets can blow – especially on cars that see regular track use and not such regular maintenance. Check for oil leaks around the seals and the side of the block.
Both the twin-carb and Spica fuel-injection system work best when professionally set up. A lot of flat-spots and rough-running issues can be traced back to the fuel system.
Mechanical components should be relatively easy to source, although this is not always the case for GTA-specific components. Many cars will feature parts from various models, the later Alfa 75 twinspark motor being a particularly favoured transplant.
DAX Cobra 427 replica 2005
Cobra by DAX , 6.3 V8 (De-dion chassis) This stunning Cobra was SVA/IVA registered sept 2005 and has only covered 3942 miles since The stunning finish of silver with grey le-mans stripes looks superb. Details include Chrome bumpers , Oil cooler, Clear front indicators, Cobra badges, Smoked sun visors, Clear wind deflectors, Chrome mirrors, Two three leg roll bars,Chrome stone guards, Large AstoFor Sale | 19 Jun 2018 | Epping, UK£ 44,995
De Tomaso Longchamp cabrio GTS RHD series 2 1984
Only 3 RHD units produced by the factory. This very rare De Tomaso Longchamp is a series 2 ( last models, better handling, wider tires " a la Pantera GTS" ). Complete history known. Completely original. No rust. Power steering, power brakes, power hood. A/C works perfect. Close to concours condition. The interior is immaculate. Extremely powerful and torquy, Superior handling.For Sale | 19 Jun 2018 | Belgium£ 150,000
Buick Riviera 1967
1967 Buick Riviera condition: excellent cylinders: 8 cylinders fuel: gas odometer: 120000 title status: clean transmission: automatic Bought from original owner! Runs great, carb was rebuilt last year! Have all maintenance records since new!! Tires are new! New water pump last year! Fresh oil change just done! Ac does work, just needs more freon. If interested contact us ASFor Sale | 19 Jun 2018 | Indianapolis, IN, USA$ 11,500
Ford Galaxie 500 1967
1967 Ford Galaxie 500 condition: excellent drive: fwd fuel: gas odometer: 49125 paint color: green size: full-size title status: clean transmission: automatic type: coupe 1967 Ford Galaxy 500 49,125 original miles. Originally sold by Borchers Ford in Dayton, Ohio. I have documentation for work preformed on car over the years. Includes dealer brochures, warranty cards, gloFor Sale | 19 Jun 2018 | Vienna, OH, USA$ 17,400
Chevrolet BelAir 1959
1959 chevrolet belair condition: good fuel: gas paint color: yellow title status: clean transmission: automatic Here we have a 1959 Belair 2 door sedan with a 455 pontiac v8 and tons of chrome. Automatic transmission, power steering and power brakes. Power doors, trunk and antenna. It is an old show car that still looks very well. It runs and drives great, just finished a 4.5 hour roFor Sale | 19 Jun 2018 | Clarksville, IN, USA$ 19,500
Dodge Polara 1964
1964 Dodge Polara 500 Convertible fuel: gas title status: clean transmission: automatic 1964 Dodge Polara 500 Convertible- 440 V-8 Engine- Don't know if it's the original engine. White Convertible Top- The Top Does Go Up and Down. Bucket Seat- Console Car, Original Gold Exterior Paint. Metallic Fawn Interior- Original Interior, 33k Miles On Odometer, Original 14" Spinner Hubcaps. HFor Sale | 19 Jun 2018 | Indianapolis, IN, USA$ 15,000
Chevrolet Corvette LT1 1972
1972 Corvette LT1 VIN: 1Z37L2S523509 condition: excellent cylinders: 8 cylinders drive: rwd fuel: gas odometer: 62000 paint color: yellow size: full-size title status: clean transmission: manual type: coupe For Sale is one 1972 Corvette LT1 Coupe. This car was originally sold by Nankivell Chevrolet in Indianapolis, In. I would be interested if anyone in that area might knFor Sale | 19 Jun 2018 | Jefferson, OH, USA$ 52,950
Cord 810 Sedan 1936
1936 Cord 810 sedan VIN: 1437S condition: good cylinders: 8 cylinders drive: fwd fuel: gas odometer: 67000 paint color: custom size: full-size title status: clean transmission: other type: sedan 1936 Cord 810 Sedan Custom Beverly 4 door V-8 Lycoming as Original Pre select 4 speed trans as Original Certified Cord by the ACD club Rich Maroon in color Tan leather interFor Sale | 19 Jun 2018 | Holly, Michigan, USA$ 62,000
The five-speed gearbox was based on the standard Giulia GT unit. It featured shorter ratios and, in some models, a magnesium bellhousing. Racing versions tended to be fitted with more robust clutches, while all GTAs should have limited-slip differentials.
Look out for worn synchros, particularly in second gear. Damaged selector forks can make it difficult to select reverse.
Suspension and brakes
The suspension set-up comprised an independent front end with coil springs and aluminium lower control arms. The rear was still a live axle with trailing arms, and you may find that few GTAs have been left in this original state.
Common upgrades include modern-specification dampers, lowered spring kits and solid bushes. Track versions tended to receive more extreme modifications to allow for increased camber and caster settings.
Brakes were discs all round, and there was no servo assistance on most of the early GTA models. Those distinctive alloy wheels were not standard on the GTA 1300 Junior; they received a style update for the GTAm models.
The biggest visual difference over the GT was the riveted aluminium skin. Thinner-gauge inner steel panels were also used, but the GTAm models reverted to the original steel bodyshell construction.
Rust was a major concern on the standard Giulia, and the GTA's aluminium panels did little to improve matters. The riveting points can corrode and rust the inner steel panels, while all the usual areas such as the arches, footwells, side sills, window frames, jacking points and suspension mounts will need close inspection, too. Is it made of metal? Check it over.
Bodywork repairs on these cars can be the costliest portion of a restoration, and badly rusted cars may be financially unviable to repair. Accident damage is common, too, so check for poorly executed resprays and panel repairs.
All GTA models were left-hand drive, and track versions were mostly stripped of all but the most essential items. Even the road-going interiors were pared down compared with those of the GT/GTV. They featured plastic side windows and numerous interior changes such as bespoke door handles and buttons, all aimed at reducing weight.
Many cars have had aftermarket racing seats and roll cages installed. Not all were fitted with plastic side windows. While individual trim items can still be sourced, the cost difference between a serviceable interior and a totally original one can be significant.
- 1963: 105 series Alfa Romeo Sprint GT introduced with Bertone-styled two-door coupe bodyshell. All forthcoming GTA models were to be based on this layout.
- 1965: Alfa Romeo Giulia 1600 GTA introduced with 113bhp 1.6-litre engine in Stradale specification. Racing versions produced up to 168bhp.
- 1967: GTA-SA built to enter FIA Group 5 racing. Featured a 1.6-litre twinspark engine and two superchargers to produce between 220bhp and 250bhp.
- 1968: GTA-SA ceases production with only ten units produced.
- 1968: GTA 1300 Junior introduced with 1.3-litre engine producing between 95bhp and 110bhp in Stradale form, and up to 163bhp in Corsa trim.
- 1969: GTAm introduced with enlarged 1.75-litre or 2.0-litre engine. Both units had Spica fuel injection and could produce up to a reputed 240bhp.
- 1969: 1600 GTA ends production. Approximately 500 of both Stradale and Corsa variants were built.
- 1971: GTAm ends production with an estimated 40 units having been produced.
- 1975: GTA 1300 Junior ends production. Approximately 193 Stradale and 300 Corsa variants were produced.
The Giulia GTAs have long been a favourite among Alfa fans, and their combination of lightweight chassis and superb handling characteristics made them excellent track machines.
The low production numbers, high attrition rate and decades of racing and modifying have made the buying process a somewhat complex affair, although buyers today have a few avenues to consider.
For the serious collector with deep pockets, there are still a handful of original cars out there – including some faithful recreations that feature most, if not all, of the period components. The GTA-SA and GTAm models are the rarest of the lot, and their values reflect this.
Then there are numerous race-prepped cars in various states of originality for those planning to enter historic events or attend track days. Many specialists also offer builds that follow the spirit of the original cars but with fully modernised running gear.
Values tend to favour the original cars, but some custom-built GTAs can command big figures, too. Whatever variant you settle on, the Giulia GTA, in all its forms, remains one of the most desirable drivers’ cars out there, and represents a high point in Alfa Romeo’s motoring history.
|1.3-litre Giulia GTA 1300|
|0-60mph||12 sec est.|
|1.6 litre Giulia Sprint GTA|
|2.0 litre GTAm|
|1.6 litre GTA-SA|
